22 kW (three-phase) · 7.4 kW (single-phase)Single-phase / Three-phase
Portable Charger
HCTS 22kW Portable EV Charger
HCTS-22 is an AC charger with a locking Type 2 socket for fixed (wall-mounted) and portable use. It delivers up to 22 kW on a three-phase supply and up to 7.4 kW on a single-phase supply, with automatic phase detection, a 3.5-inch LCD display, RFID card and mobile app support. A wall bracket and a 16 A Schuko adapter cable are included (the adapter does not limit the current; on a household socket, the device's current setting must be 16 A at most and an authorised electrician must check that the socket is suitable for continuous load); the Type 2 vehicle charging cable is not included.
22kW PowerAuto Phase DetectionRFID + Mobile App3.5" LCDBlack / White
Through authorized dealers2 Years WarrantyCE, RoHS
We manufacture; our authorized dealers sell.
- 1. Choose your product
- 2. Request a quote from a dealer
- 3. Your dealer services it
Use it on the wall, take it with you
- Portable Case
- Wall Mounting Bracket Included
- Mobile App
Power
22 kW (three-phase) · 7.4 kW (single-phase)
Single-phase / Three-phase
Durability
IP65
Operating -25°C ~ 45°C
Smart Control
Wi-Fi 2.4GHz · Bluetooth
+2 features
Warranty
2 Years
CE, RoHS
Features
3.5" LCD Screen
Wi-Fi 2.4GHz
Bluetooth
Mobile App
RFID Card
Automatic Phase Detection
Adjustable Current
Type A Residual Current (RCMU)
Portable Case
Wall Mounting Bracket Included
16 A Schuko Adapter Cable Included
Automatic Unlock on Power Failure
Water Resistant
FROM THE FACTORY
PRODUCTION PROCESS
Cable assembly and board assembly take place on the HIMS production line in Yalova.
Campaign
Campaign Visuals
9 visuals · prepared in your language · click to enlarge
Full technical data
Technical Specifications
- Number of Phases
- Single-phase / Three-phase
- Nominal Voltage
- AC 230V (Single-phase) / AC 380V – 50/60Hz
- Output Current
- 6-8-10-13-16-24-32A
- Maximum Output Power
- 22kW
- Cable Feature
- Not Included
- Socket Type
- Type 2 (Locking)
- Display
- 3.5" LCD
- Cooling
- Natural Cooling
- Protection Rating
- IP65
- Operating Temperature
- -25°C ~ 45°C
- Humidity
- ≤95% RH
- Max. Operating Altitude
- ≤2000m
- WiFi / Bluetooth
- Yes (WiFi 2.4GHz / Bluetooth)
- Start Methods
- RFID, Mobile App, Plug and Play
- LED Indicators
- Yes
- Mobile App
- Tuya Smart, Smart Life (App Store / Google Play)
- Residual Current Monitoring (RCMU)
- Type A (AC 30 mA + DC 6 mA)
- Protections
- Overheating, short circuit, over/under-voltage, overcurrent, earth fault, residual current
- Standard
- EN/IEC 61851-1:2017
- Conformity
- CE marked, RoHS
- Duration
- 2 years · Warranty Terms
Electrical 4
- Number of Phases
- Single-phase / Three-phase
- Nominal Voltage
- AC 230V (Single-phase) / AC 380V – 50/60Hz
- Output Current
- 6-8-10-13-16-24-32A
- Maximum Output Power
- 22kW
Mechanical 4
- Cable Feature
- Not Included
- Socket Type
- Type 2 (Locking)
- Display
- 3.5" LCD
- Cooling
- Natural Cooling
Environment 4
- Protection Rating
- IP65
- Operating Temperature
- -25°C ~ 45°C
- Humidity
- ≤95% RH
- Max. Operating Altitude
- ≤2000m
Communication 4
- WiFi / Bluetooth
- Yes (WiFi 2.4GHz / Bluetooth)
- Start Methods
- RFID, Mobile App, Plug and Play
- LED Indicators
- Yes
- Mobile App
- Tuya Smart, Smart Life (App Store / Google Play)
Safety & Protection 2
- Residual Current Monitoring (RCMU)
- Type A (AC 30 mA + DC 6 mA)
- Protections
- Overheating, short circuit, over/under-voltage, overcurrent, earth fault, residual current
Standards & Certification 2
- Standard
- EN/IEC 61851-1:2017
- Conformity
- CE marked, RoHS
Warranty 1
- Duration
- 2 years · Warranty Terms
Data source
- HIMS 2026 Product Catalogue (PDF)
Frequently asked questions
How many kW of power does this device deliver, and does it require a single-phase or three-phase connection?
It is compatible with both single-phase and three-phase infrastructure. It offers charging power of up to 7.4 kW in single-phase use, and up to 22 kW in three-phase use. · Supply voltage: AC 230V (Single-phase) / AC 380V – 50/60Hz
Which vehicles is it compatible with?
Compatible with all electric and plug-in hybrid vehicles with a Type 2 (IEC 62196-2) socket.
Is the charging cable included in the box?
The charging cable is not included in the box. A Type 2-compatible charging cable can be purchased separately.
How long is the warranty period?
Covered by a 2-year warranty.
Does it support remote management?
Remote monitoring and management are provided via: Wi-Fi 2.4GHz, Mobile App · For local use at the charger: Bluetooth, RFID Card
Can the HCTS-22-B be used in a fixed position as well as portably?
Yes. The HCTS-22-B can be used fixed or portable, and a wall bracket is included.
Does the HCTS-22-B detect the phase configuration?
Yes. The HCTS-22-B detects the phase configuration automatically. This does not raise the power limits of the vehicle or electrical installation.
What is the HCTS-22-B display size?
The HCTS-22-B has a 3.5-inch LCD.
What is the standby power of the HCTS-22-B?
The HCTS-22-B standby power is 3 W. This is separate from the charging power supplied to the vehicle.
Use together
Compatible Cables and Accessories
Compatible Vehicles
Compatible with electric and plug-in hybrid vehicles that support the Type 2 connector.
Select your vehicle to calculate the estimated charging time and cost.
- TOGG T10X · Made in Türkiye · Calculate charging time
- TOGG T10F · Made in Türkiye · Calculate charging time
- Tesla Model Y · Calculate charging time
- Tesla Model 3 · Calculate charging time
- MG4 Electric · Calculate charging time
- MG ZS EV · Calculate charging time
- BYD Atto 3 · Calculate charging time
- BYD Dolphin · Calculate charging time
- BYD Seal · Calculate charging time
- Hyundai Ioniq 5 · Calculate charging time
- Hyundai Kona Electric · Calculate charging time
- Hyundai Inster · Calculate charging time
- Kia EV6 · Calculate charging time
- Kia Niro EV · Calculate charging time
- Renault Megane E-Tech · Calculate charging time
- Renault Zoe · Calculate charging time
- Citroën ë-C3 · Calculate charging time
- Fiat Grande Panda Electric · Calculate charging time
- Opel Frontera Electric · Calculate charging time
- Volvo EX30 · Calculate charging time
- BMW iX1 · Calculate charging time
- BMW iX3 · Calculate charging time
- BMW i4 · Calculate charging time
- Mercedes EQE · Calculate charging time
- Mercedes EQS · Calculate charging time
- VW ID.4 · Calculate charging time
- VW ID.3 · Calculate charging time
- Audi Q4 e-tron · Calculate charging time
- Porsche Taycan · Calculate charging time
- Ford Mustang Mach-E · Calculate charging time
- MINI Countryman SE · Calculate charging time
- KGM Torres EVX · Calculate charging time
6-Layer Security System
Overcurrent
Automatic cut-off
Overvoltage
Voltage protection
Temperature
Overheating protection
Short Circuit
Instant cut-off
Earthing
Check
Residual Current
RCMU Type A
